CP-C Type Small Package-Hardware Counting Packaging Machine
The CP-C Hardware Counting and Packaging Machine is a fully automated packaging device suitable for various furniture components, including screws, nuts, bolts, washers, furniture kits, hardware fittings, fasteners, and small parts. It features high-precision, high-efficiency packaging capabilities, capable of counting or weighing according to your requirements, and automatically completing the packaging process, thereby significantly reducing labor costs.
The CP-C Hardware Counting Packaging Machine delivers outstanding performance, designed to provide efficient packaging solutions. Its automated operation and high-precision counting/weighing capabilities make it an ideal choice for furniture manufacturing enterprises. Whether handling large or small batches of furniture components, this packaging machine ensures precise and rapid packaging to meet your requirements.
This fully automatic packaging machine not only achieves high-precision packaging but also offers user-friendly operation, thereby enhancing work efficiency. It serves as an ideal partner in furniture manufacturing and assembly processes, providing an exceptional packaging solution that helps boost production efficiency, reduce waste, and deliver high-quality packaging for furniture components.
Sample
Video
Structure
PLC Control System
Chain Bucket Conveyor Line
Fiber-optics Counting System
Technical Parameters
|
Model： |
CP-C-320 |
CP-C-420 |
|
Packaging Speed： |
Mixed bag: 30-60 bags/Min; Grid bag: 40-60 grids/Min |
Mixed bag: 30-50 bags/Min; Grid bag: 30-50 grids/Min |
|
Bag Size： |
L 50-180MM; W 40-150MM(Bag maker needs to be replaced) |
L 50-180MM ;W 90-200MM(Bag maker needs to be replaced) |
|
Maximum Film Width： |
≤320MM |
≤420MM |
|
Voltage： |
220V 50/60HZ |
220V 50/60HZ |
|
Total Weight： |
300KG |
400KG |
|
Total Power： |
1.52KW |
2.52KW |
|
Size： |
6000*1500*1600MM |
7000*1500*1600MM |
Specific Description
|
01 |
Advanced PLC control system, stable and superior performance. |
|
02 |
Color touch screen operation interface, adjustable parameter settings, simple operation, convenient adjustment |
|
03 |
Fully functional, the equipment can automatically complete the counting, filling, bag making, sealing, coding, exhaust, packaging and other functions |
|
04 |
Intelligent temperature controller, precise temperature control, firm sealing, smooth and beautiful bag shape |
|
05 |
The use of high quality vibration plate sort feeding, feeding fast and smooth, according to customer materials customized tray to meet different needs |
|
06 |
Optical fiber counting system, fast response speed, high sensitivity, can ensure accurate counting |
|
07 |
The equipment is equipped with electrical safety protection device and protective cover, which has reliable safety performance |
|
08 |
The whole machine is made of high quality steel, the structure is stable, the appearance is covered with stainless steel material, beautiful and durable |
Product Usage
|
01 |
Suitable for 1 -3 kinds of materials mixed packaging, divided bag |
|
02 |
Used for screws, nuts, gaskets, nails, rubber parts, plastic parts, hardware, furniture accessories and other material products |
|
03 |
Used in fasteners, furniture, supports, bathroom, toys, automobiles, electronics, electrical appliances, lighting, stationery and other industries |
optional equipment
